How does VIM30FH sit between adjacent models?
Its published power is 30W, between VIM20FH at 20W and VIM50FH at 50W. All three use the listed 1080nm wavelength; the table does not compare their results on a particular sample.
Laser Marking Machine
VIM30FH — VIM-FH Laser Marking Machine
VIM30FH is the 30W handheld fiber laser marker between the 20W and 50W entries in the VIM-FH table. It retains the published 1080nm wavelength. A useful comparison starts with access to the component: the target face, the head approach and the way the part is supported during marking.
Keep those requirements unchanged when comparing the adjacent power choices. A request that changes both the artwork and the component position cannot isolate the equipment question. The table supplies power values, but it does not establish a production cycle, marking depth or guaranteed result for the proposed material.
Technical specifications
| Specification | VIM30FH |
|---|---|
| Laser Power | 30W |
| Laser Wavelength | 1080nm |
| Making Range | 110*110mm, 200*200mm |
| Laser Generator | Raycus, IPG |
| Minimum Line Width | 10 Microns |
| Minimum Characters | 0.15mm |
| Usage Environment | Clean and Dust-Free or Dust-Less |
| Graphic Format Supported | bmp, jpg, gif, png, tif, ai, dxf, dst, plt, etc |
| Laser Module Life | >100000 Hours |
Configuration options vary by model. Confirm the final specification, selected components and operating requirements with your quotation.
Other models in this series
VIM30FH fiber laser marking machine structure
The handheld FH structure includes a fiber generator, air cooling, a galvo scanner and a field lens. Ask for the head dimensions and connection arrangement relevant to the offered machine. A handheld description alone does not show that the head can reach every recessed surface or clear the surrounding features of a large part.
The controls support setting adjustments and monitoring. Describe which settings the operator needs to review during a job change and request the corresponding operating information. No named software package, automatic recipe library or connection to an existing production system is established by the model specification.
The red dot pointer provides a visible reference for positioning the material or marking area. The table separately states a 10 Microns minimum line width and a 0.15mm minimum character dimension. Those optical and graphic references should not be converted into an automatic alignment accuracy or a readability guarantee.
VIM30FH work preparation
The published application examples cover metals and plastics, with serial numbers, logos and part identification among the stated uses. Identify the particular material and surface finish in your enquiry. A general material name is not evidence that the intended colour, depth or durability has been demonstrated on the part.
For a difficult approach, supply a drawing that shows the target face and surrounding obstructions. Mark the available support points and intended head direction. These details help define the proposed job without claiming that confined positions, irregular shapes or every orientation fall within a proven operating capability.
VIM30FH 30W laser marker configuration
Raycus and IPG are listed generator choices. The two marking ranges are 110*110mm and 200*200mm. Record the generator and selected optical arrangement alongside the 30W model in the offer, because the power value alone does not identify those choices or the accessories supplied with them.
The source accepts graphic formats including bmp, jpg, gif, png, tif, ai, dxf, dst and plt. Send a dimensioned view with the working file. If several surfaces need marks, label them separately rather than treating all artwork as one unlocated collection of graphics.
The installation specification calls for a clean, dust-free or low-dust environment. A door or panel opening is the stated trigger for the safety interlock to stop the machine. Confirm the actual protective arrangement and operating instructions. The >100000 Hours Laser Module Life field does not define warranty duration or maintenance terms.
Product questions
Can the head reach a recessed marking face?
The source does not provide a universal access guarantee. Send the recess and surrounding dimensions, then review the offered head geometry and proposed approach against that drawing.
Is either marking range included automatically?
The table gives 110*110mm and 200*200mm as choices. The quotation should state the selected lens and range, together with any alternative optics included in the supply.
Are the metal and plastic examples tested applications?
They are material examples from the published description. The exact grade, finish and requested mark still need job-specific review; this page does not present a customer test or performance result.
Is the module-life figure a warranty?
No. The source labels >100000 Hours as Laser Module Life. Obtain the actual warranty and service conditions separately rather than interpreting that field as coverage for the entire machine.
